SECTION 24 - SWING BOLTS & FORK ENDS
WDS
WDS
www.wdsltd.co.uk24-3
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSwing Bolt -
Heavy Duty
Swing Bolt
Heavy Duty -
Stainless
WDS 611
WDS 810
MATERIAL
-
Stainless Steel
BS 970 Gr 316S11
See 611 Series for this part
in Steel
D L L1 D1 D2 E
(g) WDS No.
M4 30 20 4 10 5
5 611-251
M5 40 25 5 12 6
5 611-252
M5 60 30 5 12 6 10 611-253
M6 40 25 6 14 7 10 611-254
M6 50 30 6 14 7 15 611-255
M6 75 40 6 14 7 20 611-256
M8 40 25 8 18 9 20 611-257
M8 50 30 8 18 9 25 611-258
M8 75 40 8 18 9 35 611-259
M10 50 30 10 20 12 40 611-260
M10 75 40 10 20 12 50 611-261
M10 100 40 10 20 12 65 611-262
D L L1 D1 D2 E
(g) WDS No.
M12 75 50 12 25 14 80 611-263
M12 100 60 12 25 14 100 611-264
M12 125 60 12 25 14 125 611-265
M12 150 60 12 25 14 145 611-266
M14 100 60 14 28 16 140 611-267
M14 125 60 14 28 16 170 611-268
M16 125 60 16 32 17 220 611-269
M16 150 75 16 32 17 255 611-270
M20 150 75 18 40 22 435 611-271
M20 175 100 18 40 22 470 611-272
M24 150 75 22 48 25 650 611-273
M24 200 100 22 48 25 750 611-274
D
L
D1
D2
E
L1
(g)
WDS No.
M5
40
5
12
6
25
8
810-20540
M5
60
5
12
6
30
16
810-20560
M6
40
6
14
7
25
10
810-20640
M6
50
6
14
7
30
15
810-20650
M8
50
8
18
9
30
25
810-20850
M8
75
8
18
9
40
35
810-20875
M10
50
10
20
12
30
35
810-21050
M10
75
10
20
12
40
65
810-21075
M10
100
10
20
12
50
100
810-210100
M12
75
12
25
14
50
80
810-21275
M12
100
12
25
14
60
100
810-212100
M12
125
12
25
14
60
125
810-212125
M16
100
16
32
17
60
180
810-216100
M16
125
16
32
17
60
220
810-216125
M16
150
16
32
17
75
260
810-216150
316
MATERIAL
-
High tensile steel
Chemical black finish
BS. 970 Gr. 606 M36T
See 810 Series for this part in
Stainless
L
L1
D
D1
E
D2
+0.025
+0.130
+0.0
- 0.13
L
L1
D
D1
E
D2
+0.025
+0.130
+0.0
- 0.13
