SECTION 24 - SWING BOLTS & FORK ENDS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk24-4
WDS
www.wdsltd.co.ukSwing Bolt Heavy
Duty - Stainless
WDS 8910
MATERIAL
-
Stainless Steel
BS 970 Gr 303S31
See 611 Series for this part in
Steel
D
L
D1
D2
E
L1
(g)
WDS No.
M5
40
5
12
6
25
8
8910-20540
M5
60
5
12
6
30
16
8910-20560
M6
40
6
14
7
25
10
8910-20640
M6
50
6
14
7
30
15
8910-20650
M8
50
8
18
9
30
25
8910-20850
M8
75
8
18
9
40
35
8910-20875
M10
50
10
20
12
30
35
8910-21050
M10
75
10
20
12
40
65
8910-21075
M10
100
10
20
12
50
100
8910-210100
M12
75
12
25
14
50
80
8910-21275
M12
100
12
25
14
60
100
8910-212100
M12
125
12
25
14
60
125
8910-212125
M16
100
16
32
17
60
180
8910-216100
M16
125
16
32
17
60
220
8910-216125
M16
150
16
32
17
75
260
8910-216150
L
L1
D
D1
E
D2
+0.025
+0.130
+0.0
- 0.13
Fork End
WDS 659
MATERIAL
-
Steel BS.970 Gr.070M20
Chemical black finish
D
A
B
B1
D1 D2 H7
E
E1
L
L1
T
(g) WDS No.
M6
12
16
7
12
6
14
7
20
12
12
25 659-201
M8
16
20
9
15
8
18
9
23
16
14
50 659-202
M10
20
25
11
17
10
22
11
28
20
18
85 659-203
M10
20
25
12
17
10
22
11
28
20
18
100 659-2035
M12
25
32
13
24
12
28
13
35
25
22
195 659-204
M12
25
32
14
24
12
28
13
35
25
22
200 659-2045
'
/
/
$
'
(
%
%
(
