Shoulder Screw -
Inch
WDS 615
MATERIAL
-
Steel BS.970 Gr.220M07
Chemical black finish
D
D1
L
D2
H
L1
(g)
WDS No.
BA/BSF
WDS No.
UNC
2 BA
0.250"
0.188"
12.7
4
6.4
5
615-15
-
2 BA
0.250"
0.250"
12.7
4
6.4
5
615-16
-
10 UNC 0.250"
0.188"
12.7
4
6.4
5
-
615-01
10 UNC 0.250"
0.250"
12.7
4
6.4
5
-
615-02
1
⁄
4
0.3125"
0.250"
12.7
4
7.9
10
615-17
615-03
1
⁄
4
0.3125"
0.313"
12.7
4
7.9
10
-
615-04
1
⁄
4
0.3125"
0.375"
12.7
4
7.9
20
615-19
615-05
1
⁄
4
0.375"
0.250"
15.9
4
7.9
12
615-20
615-06
1
⁄
4
0.375"
0.313"
15.9
4
7.9
15
615-21
615-07
5
⁄
16
0.375"
0.375"
15.9
4.8
11.1
16
615-22
615-08
5
⁄
16
0.375"
0.500"
15.9
4.8
11.1
20
615-23
615-09
5
⁄
16
0.500"
0.375"
19.1
4.8
11.1
25
-
615-10
3
⁄
8
0.500"
0.500"
19.1
6.4
12.7
30
615-25
615-11
3
⁄
8
0.500"
0.625"
19.1
6.4
12.7
35
-
615-12
3
⁄
8
0.500"
0.750"
19.1
6.4
12.7
40
-
615-13
Shoulder Screw -
Metric
WDS 615
MATERIAL
-
Steel BS.970 Gr. 220M07
Chemical black finish
Metric
D
D1
L
D2
H
L1
(g)
WDS No.
M5
6
6
13
4
6
5
615-2006
M5
7
6
13
4
6
6
615-2008
M6
8
6
13
4
8
6
615-201
M6
8
8
13
4
8
7
615-2015
M6
8
10
13
4
8
8
615-202
M8
10
10
16
5
11
17
615-203
M8
10
12
16
5
11
18
615-204
M10
12
12
19
6
13
34
615-205
M10
12
16
19
6
13
35
615-2055
M10
13
16
19
4.5
13
32
615-2058
M10
14
16
22
6
13
42
615-206
'
'
/
/
+
'
'
'
/
/
+
'
