SECTION 26 - NUTS, WASHERS, SCREWS & STUDS
WDS
WDS
www.wdsltd.co.uk26-31
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukThread Insert -
Stainless
WDS 830
MATERIAL
-
Stainless steel BS 970 303S31
See 415 Series for this part in
Carbon Steel and for Fitting
Tool
D
D1
L
D2
D3
L1
(g)
WDS No.
M5 x 0.8
M8 x 1.25
8
6.9
8.3
9.5
1
830-201
M6 x 1.0 M10 x 1.25
10
8.8
10.3
11.5
2
830-202
M8 x 1.25 M12 x 1.25
12
10.8
12.3
13.5
3
830-203
M8 x 1.0 M12 x 1.25
12
10.8
12.3
13.5
3
830-204
M10 x 1.5 M14 x 1.5
14
12.8
14.3
15.5
5
830-205
M10 x 1.25 M14 x 1.5
14
12.8
14.3
15.5
5
830-206
M12 x 1.75 M16 x 1.5
16
14.8
16.3
17.5
8
830-207
M12 x 1.25 M16 x 1.5
16
14.8
16.3
17.5
8
830-208
Thread Inserts
WDS 415
MATERIAL
-
Carbon steel C1215 BS
Gr 230M07
Chemical black finish
Sizes to M6 have 2 locking pins
Sizes from M8 upwards have 4
locking pins
See 830 Series for this part in
Stainless Steel
D
D1
L
D2
D3
L1
(g)
WDS No.
M5 x 0.8
M8 x 1.25
8
6.9
8.3
9.5
1
415-201
M6 x 1.0 M10 x 1.25
10
8.8
10.3
11.5
2
415-202
M8 x 1.25 M12 x 1.25
12
10.8
12.3
13.5
3
415-203
M8 x 1.0 M12 x 1.25
12
10.8
12.3
13.5
3
415-204
M10 x 1.5 M14 x 1.5
14
12.8
14.3
15.5
5
415-205
M10 x 1.25 M14 x 1.5
14
12.8
14.3
15.5
5
415-206
M12 x 1.75 M16 x 1.5
16
14.8
16.3
17.5
8
415-207
M12 x 1.25 M16 x 1.5
16
14.8
16.3
17.5
8
415-208
'
/
'
/RFNLQJ SLQ
'
/ 0,1
'
,QVHUW
3UHSDUDWLRQ
'
/
'
/RFNLQJ SLQ
'
/ 0,1
'
,QVHUW
3UHSDUDWLRQ
303
Note: The ‘D’ dimension corresponds to the same ‘D’ dimension in the Fitting Tool table.
Note: The ‘D’ dimension corresponds to the same ‘D’ dimension in the Fitting Tool table.
