SECTION 27 - METAL PROFILES WDS
& 0845 606 66 77 • : • * 27-2
WDS
L-Section - Cast
Iron
WDS 913
MATERIAL -
Cast iron
BS EN 1561 1997-EN/GJL-250
(BS 1452 Gr 250)
See 912 Series for Heavy
Duty Cast Iron L-Section and
935 Series for Cast Iron, Un
Equal L-Section, Aluminium
L-Section 944 Series
B H S L (kg) WDS No.
50 50 12 100 0.8 913-401100
50 50 12 200 1.5 913-401200
50 50 12 300 2.3 913-401300
50 50 12 400 3 913-401400
50 50 12 500 3.8 913-401500
50 50 12 600 4.6 913-401600
50 50 12 800 6 913-401800
50 50 12 1000 7.6 913-4011000
63 63 14 100 1.1 913-402100
63 63 14 200 2.3 913-402200
63 63 14 300 3.4 913-402300
63 63 14 400 4.5 913-402400
63 63 14 500 5.6 913-402500
63 63 14 600 6.8 913-402600
63 63 14 700 7.9 913-402700
63 63 14 800 9 913-402800
63 63 14 1000 11.2 913-4021000
80 80 16 100 1.7 913-403100
80 80 16 200 3.3 913-403200
80 80 16 300 5 913-403300
80 80 16 400 6.6 913-403400
80 80 16 500 8.3 913-403500
80 80 16 600 10 913-403600
100 100 20 100 2.6 913-404100
100 100 20 200 5.2 913-404200
100 100 20 300 7.8 913-404300
100 100 20 400 10.4 913-404400
100 100 20 500 13 913-404500
100 100 20 600 15.5 913-404600
100 100 20 700 18.1 913-404700
100 100 20 800 20.7 913-404800
125 125 22 100 3.6 913-405100
125 125 22 200 7.2 913-405200
125 125 22 300 10.8 913-405300
125 125 22 400 14.4 913-405400
125 125 22 500 18 913-405500
125 125 22 600 21.7 913-405600
125 125 22 700 25.3 913-405700
125 125 22 800 28.8 913-405800
150 150 25 100 4.9 913-4055100
B H S L (kg) WDS No.
150 150 25 200 9.9 913-4055200
150 150 25 300 15 913-4055300
150 150 25 400 20 913-4055400
150 150 25 500 25 913-4055500
150 150 25 600 30 913-4055600
150 150 25 700 35 913-4055700
150 150 25 800 40 913-4055800
160 160 25 100 5.3 913-406100
160 160 25 200 10.6 913-406200
160 160 25 300 15.9 913-406300
160 160 25 400 21.2 913-406400
160 160 25 500 26.5 913-406500
160 160 25 600 31.8 913-406600
160 160 25 700 37.1 913-406700
160 160 25 800 42.4 913-406800
200 200 32 100 8.5 913-407100
200 200 32 200 17 913-407200
200 200 32 300 25.4 913-407300
200 200 32 400 33.9 913-407400
200 200 32 500 42.4 913-407500
200 200 32 600 50.9 913-407600
200 200 32 700 59.3 913-407700
200 200 32 800 67.8 913-407800
250 250 36 100 12 913-408100
250 250 36 200 24 913-408200
250 250 36 300 36 913-408300
250 250 36 400 48 913-408400
250 250 36 500 60 913-408500
250 250 36 600 72 913-408600
250 250 36 700 84 913-408700
250 250 36 800 96 913-408800
315 315 38 100 16 913-409100
315 315 38 200 32 913-409200
315 315 38 300 49 913-409300
315 315 38 400 64 913-409400
315 315 38 500 80 913-409500
315 315 38 600 96 913-409600
315 315 38 700 112 913-409700
315 315 38 800 128 913-409800
The ends of all cut sections are
supplied sawn such that they will
clean up to the lengths stated in this
catalogue.
+
%
