SECTION 26 - NUTS, WASHERS, SCREWS & STUDS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk26-32
WDS
www.wdsltd.co.ukThread Insert
Heavy Duty
WDS 415
MATERIAL
-
Body - Carbon Steel
Keys - 302 CRES
Sizes to M6 have 2 locking pins
Sizes from M8 upwards have 4
locking pins
See 830 Series for this part in
Stainless Steel
D
D1
L
D2
D3
L1
(g)
WDS No.
M5 x 0.8 M10 x 1.25
10
8.8
10.3
9.5
4
415-401
M6 x 1.0 M12 x 1.25
12
10.8
12.25
14.5
7
415-402
M8 x 1.25 M14 x 1.5
14
12.8
14.25
16.5
9
415-403
M8 x 1.0
M14 x 1.5
14
12.8
14.25
16.5
9
415-404
M10 x 1.5 M16 x 1.5
16
14.75
16.25
18.5
13
415-405
M10 x 1.25 M16 x 1.5
16
14.75
16.25
18.5
13
415-406
M12 x 1.75 M18 x 1.5
18
16.75
18.25
20.5
9
415-407
M12 x 1.25 M18 x 1.5
18
16.75
18.25
20.5
16
415-408
M16 x 2.0 M22 x 1.5
22
20.5
22.25
24.5
27
415-411
'
/
'
/RFNLQJ SLQ
'
/ 0,1
'
,QVHUW
3UHSDUDWLRQ
Thread Insert -
Stainless
Heavy Duty
WDS 830
MATERIAL
-
Stainless steel BS 970 303S31
See 415 Series for this part in
Carbon Steel and for Fitting
Tool
D
D1
L
D2
D3
L1
(g)
WDS No.
M5 x 0.8 M10 x 1.25
10
8.8
10.3
9.5
4
830-401
M6 x 1.0 M12 x 1.25
12
10.8
12.25
14.5
6
830-402
M8 x 1.25 M14 x 1.5
14
12.8
14.25
16.5
9
830-403
M8 x 1.0
M14 x 1.5
14
12.8
14.25
16.5
9
830-404
M10 x 1.5 M16 x 1.5
16
14.75
16.25
18.5
13
830-405
M10 x 1.25 M16 x 1.5
16
14.75
16.25
18.5
13
830-406
M12 x 1.75 M18 x 1.5
18
16.75
18.25
20.5
17
830-407
M12 x 1.25 M18 x 1.5
18
16.75
18.25
20.5
16
830-408
M16 x 2.0 M22 x 1.5
22
20.5
22.25
24.5
26
830-411
'
/
'
/RFNLQJ SLQ
'
/ 0,1
'
,QVHUW
3UHSDUDWLRQ
303
Note: The ‘D’ dimension corresponds to the same ‘D’ dimension in the Fitting Tool table.
Note: The ‘D’ dimension corresponds to the same ‘D’ dimension in the Fitting Tool table.
