SECTION 28 - CLAMPS WDS
WDS
28-3 & 0845 606 66 77 • : • *
For use with clamp set 354-201 &
354-202
Cam Operated
Clamp Assembly
Eccentric Cam
Lever
WDS 354
WDS 355
MATERIAL -
Carbon Steel hardened
Chemical black finish
MATERIAL -
Carbon Steel hardened
Chemical black finish
D A B H L L1 L2 L3 (g) WDS No.
M12 20 30 26-35 100 47 43 22 1.0 354-201
M16 20 40 26-35 125 49 66 32 1.4 354-202
D A B C L L1 W (g) WDS No.
10 24 38 11 165 23 10 300 355-201
'
$+
6
-
.
3
)
) [ 3
- URWDWLRQ 6
. URWDWLRQ 6 /
/ /
%
/ FWUV
&
/
%
'
/
$
:
&
/
%
'
/
$
:
Cam Operated
Clamp Assembly
WDS 356
MATERIAL -
Carbon Steel hardened
Chemical black finish
D D1 A B H L L1 L2 (g) WDS No.
M12 M12 20 30 30-45 100 43 22 1.0 356-201
M16 M12 20 40 35-50 125 66 32 1.45 356-202
' '
+ $6
-
.
)
3
%
/ FWUV
/
/ - URWDWLRQ JLYHV 6
. URWDWLRQ JLYHV 6
) [ 3
