SECTION 5 - HAND KNOBS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk5-18
WDS
www.wdsltd.co.ukSwivel End
Torque Screw
WDS 706
MATERIAL
-
Head - Steel Bs.970 Gr.220M07
Screw - Steel Bs.970 Gr.212A42
Chemical Black Finish
For use with 671 Swivel Pads
Metric
D
L
D1
D2
D3
F1
F2
H
L1
L2
R
(g) WDS No.
M6
40
25
4.5
4.1
4
80
20
6
2.5
3
75 706-401
M6
60
25
4.5
4.1
4
80
20
6
2.5
3
80 706-402
M8
60
25
6
5.3
4
65
20
7.5
3
5
85 706-403
M8
80
25
6
5.3
4
65
20
7.5
3
5
90 706-404
M10
60
25
8
7.2
4
55
20
9
4.5
6
95 706-405
M10
80
25
8
7.2
4
55
20
9
4.5
6
105 706-406
M12
80
25
8
7.2
4
45
20
10
4.5
6
120 706-407
M12 100
25
8
7.2
4
45
20
10
4.5
6
135 706-408
F1 = Minimum end pressure (kg)
F2 = Maximum end pressure (kg)
'
'
'
+
'
/
/
/
5
) 0LQLPXP HQG SUHVVXUH NJ
) 0D[LPXP HQG SUHVVXUH NJ
Hand Nut Thru Hole
WDS 8198
MATERIAL
-
Thermoplastic, black
Insert- Steel, zinc plated
D
D1
D2
H
H1
T
(g)
WDS No.
M6
70
19
20
7
12
11
8198-221
M8
70
19
20
7
12
10
8198-222
'
+
'
'
