SECTION 5 - HAND KNOBS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk5-14
WDS
www.wdsltd.co.ukSwivel End
Adjusting Screw
Swivel End
Adjusting Screw
WDS 822
WDS 8922
MATERIAL
-
Stainless Steel BS 970
Gr 316S11
See 672 Series for this part
in Steel
MATERIAL
Stainless Steel BS 970 Gr 303S31
See 672 Series for this part in
Steel
For use with 821 Swivel Pads
For use with 821 Swivel Pads
D
L
D1
D2
D3
E
L1
L2
R
(g)
WDS No.
M6
30
16
4.5
4.1
6
6
2.5
3
20
822-40630
M6
50
16
4.5
4.1
6
6
2.5
3
20
822-40650
M8
40
22
6
5.3
8
7.5
3
5
35
822-40840
M8
60
22
6
5.3
8
7.5
3
5
40
822-40860
M10
50
25
8
7.2
10
9
4.5
6
60
822-41050
M10
70
25
8
7.2
10
9
4.5
6
80
822-41070
M12
90
30
8
7.2
12
10
4.5
6
130
822-41290
D
L
D1
D2
D3
E
L1
L2
R
(g)
WDS No.
M6
50
16
4.5
4.1
6
6
2.5
3
20
8922-40650
M8
40
22
6
5.3
8
7.5
3
5
35
8922-40840
M8
60
22
6
5.3
8
7.5
3
5
40
8922-40860
M10
50
25
8
7.2
10
9
4.5
6
60
8922-41050
M10
70
25
8
7.2
10
9
4.5
6
80
8922-41070
M12
90
30
8
7.2
12
10
4.5
6
130 8922-41290
'
'
(
5
'
'
/
/
/
'
'
(
5
'
'
/
/
/
316
303
gap
1
2
