SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-11
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSwivel End
Screw
Swivel End Screw
WDS 820
WDS 8920
MATERIAL
-
Stainless Steel
BS 970 Gr 316S11
See 670 Series for this part
in Steel
MATERIAL
-
Stainless Steel
BS 970 Gr 303S31
See 670 Series for this part in
Steel
For use with 821 Swivel Pads
For use with 821 Swivel Pads
D
L
D1
D2
L1
L2
R
(g)
WDS No.
M6
40
4.5
4.1
6
2.5
3
6
820-40640
M6
60
4.5
4.1
6
2.5
3
9
820-40660
M8
50
6
5.3
7.5
3
5
15
820-40850
M8
70
6
5.3
7.5
3
5
20
820-40870
M10
60
8
7.2
9
4.5
6
25
820-41060
M10
80
8
7.2
9
4.5
6
35
820-41080
M12
70
8
7.2
10
4.5
6
45
820-41270
M12
100
8
7.2
10
4.5
6
65
820-412100
D
L
D1
D2
L1
L2
R
(g)
WDS No.
M6
40
4.5
4.1
6
2.5
3
6
8920-40640
M8
50
6
5.3
7.5
3
5
15
8920-40850
M10
60
8
7.2
9
4.5
6
25
8920-41060
M12
70
8
7.2
10
4.5
6
45
8920-41270
/
/
/
'
'
'
5
/
/
/
'
'
'
5
316
303
