SECTION 5 - HAND KNOBS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk5-10
WDS
www.wdsltd.co.ukTommy Bar Screw
Swivel End Screw
WDS 833
WDS 670
MATERIAL
-
Stainless Steel
BS 970 Gr 316S11
See 663 Series for this part in
Steel
MATERIAL
-
Steel BS.970 Gr.212A42
Chemical black finish
See 820 Series for this part in
Stainless Steel
For use with 671 Swivel Pads
P = safe working load in kg (for static load only)
D
L
D1
D2
D3
L1
L2
L3
L4
(g) WDS No.
M6
25
10
4.5
5
32
12
3
3
11 833-20625
M6
35
10
4.5
5
32
12
3
3
16 833-20635
M6
50
10
4.5
5
32
12
3
3
20 833-20650
M8
25
12
6
5
45
14
4
3
25 833-20825
M8
35
12
6
5
45
14
4
3
29 833-20835
M8
50
12
6
5
45
14
4
3
34 833-20850
M10
35
16
7.8
5
45
16
6
3
42 833-21035
M10
50
16
7.8
5
45
16
6
3
48 833-21050
M10
60
16
7.8
5
45
16
6
3
57 833-21060
M12
50
20
9.4
6.5
50
19
6
3
80 833-21250
M12
75
20
9.4
6.5
50
19
6
3
105 833-21275
M12
100
20
9.4
6.5
50
19
6
3
120 833-212100
D
L
D1
D2
L1
L2
R
P
(g)
WDS No.
M6
50
4.5
4.1
6
2.5
3
110
9
670-400650
M8
50
6
5.3
7.5
3
5
170
15
670-400850
M8
75
6
5.3
7.5
3
5
170
23
670-400875
M10
50
8
7.2
9
4.5
6
320
25
670-40150
M10
75
8
7.2
9
4.5
6
320
37
670-40175
M10
125
8
7.2
9
4.5
6
320
62
670-401125
M12
75
8
7.2
10
4.5
6
320
54
670-40275
M12
125
8
7.2
10
4.5
6
320
90
670-402125
D
L
D1
D2
L1
L2
R
P
(g)
WDS No. UNC
1
⁄
4
50
4.5
4.1
6
2.5
3
110
9
670-60
1
⁄
2
150
8
7.2
10
4.5
6
320
108
670-69
Metric
Inch
/
'
'
/
/
/
'
'
/
/
/
/
'
'
'
5
3 VDIH ZRUNLQJ ORDG LQ NJ
6WDWLF ORDG RQO\
316
