SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-61
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukGrip Ball
WDS 8470
MATERIAL
-
Body - Thermoplastic
Screw - Steel - zinc plated
Screw - Stainless Steel - 303 S31
Black Grey - RAL 7021
D
D1
D2
D3
H
H1
L
(g)
WDS No.
Steel Screw
WDS No.
Stainless Steel
Screw
M6
25
12
17
25
2.5
15
20
8470-402BG 8470-502BG
M6
25
12
17
25
2.5
20
21
8470-404BG 8470-504BG
M6
25
12
17
25
2.5
25
22
8470-406BG 8470-506BG
M6
25
12
17
25
2.5
30
24
8470-408BG 8470-508BG
M8
32
15.5
19
33
3.2
20
36
8470-410BG 8470-510BG
M8
32
15.5
19
33
3.2
25
38
8470-412BG 8470-512BG
M8
32
15.5
19
33
3.2
30
40
8470-414BG 8470-514BG
M8
32
15.5
19
33
3.2
40
44
8470-416BG 8470-516BG
M10
40
19
23
41.5
4
20
63
8470-418BG 8470-518BG
M10
40
19
23
41.5
4
30
69
8470-420BG 8470-520BG
M10
40
19
23
41.5
4
40
75
8470-422BG 8470-522BG
M10
50
24
31
51
5
20
91
8470-424BG 8470-524BG
M10
50
24
31
51
5
30
97
8470-426BG 8470-526BG
M10
50
24
31
51
5
40
103 8470-428BG 8470-528BG
M12
50
24
31
51
5
20
106 8470-430BG 8470-530BG
M12
50
24
31
51
5
30
115 8470-432BG 8470-532BG
M12
50
24
31
51
5
40
123 8470-434BG 8470-534BG
'
'
'
+
+
'
/
'
'
'
+
+
'
/
ZP
303
RAL
7021
