www.wdsltd.co.ukGrip Ball
WDS 8470
MATERIAL
-
Body - Thermoplastic
Screw - Steel - zinc plated
Screw - Stainless Steel - 303 S31
Pale Grey - RAL 7035
D
D1
D2
D3
H
H1
L
(g)
WDS No.
Steel Screw
WDS No.
Stainless Steel
Screw
M6
25
12
17
25
2.5
15
20 8470-402PG 8470-502PG
M6
25
12
17
25
2.5
20
21 8470-404PG 8470-504PG
M6
25
12
17
25
2.5
25
22 8470-406PG 8470-506PG
M6
25
12
17
25
2.5
30
24 8470-408PG 8470-508PG
M8
32
15.5
19
33
3.2
20
36 8470-410PG 8470-510PG
M8
32
15.5
19
33
3.2
25
38 8470-412PG 8470-512PG
M8
32
15.5
19
33
3.2
30
40 8470-414PG 8470-514PG
M8
32
15.5
19
33
3.2
40
44 8470-416PG 8470-516PG
M10
40
19
23
41.5
4
20
63 8470-418PG 8470-518PG
M10
40
19
23
41.5
4
30
69 8470-420PG 8470-520PG
M10
40
19
23
41.5
4
40
75 8470-422PG 8470-522PG
M10
50
24
31
51
5
20
91 8470-424PG 8470-524PG
M10
50
24
31
51
5
30
97 8470-426PG 8470-526PG
M10
50
24
31
51
5
40
103 8470-428PG 8470-528PG
M12
50
24
31
51
5
20
106 8470-430PG 8470-530PG
M12
50
24
31
51
5
30
115 8470-432PG 8470-532PG
M12
50
24
31
51
5
40
123 8470-434PG 8470-534PG
'
+
+
'
/
'
'
'
+
+
'
/
ZP
303
RAL
7035
