SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-65
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukGrip Ball with
Revolving Spindle
Grip Ball with
Revolving Spindle
WDS 8470
WDS 8470
MATERIAL
-
Body - Thermoplastic
Spindle - Steel - zinc plated
Spindle - Stainless Steel - 303 S31
MATERIAL
-
Body - Thermoplastic
Spindle - Steel - zinc plated
Spindle - Stainless Steel - 303 S31
Black Grey - RAL 7021
Pale Grey - RAL 7035
D D1 D2 D3 D4 H H1 L1 L2 L3 L4 S
(g) WDS No.
Steel Spindle
WDS No.
Stainless Steel
Spindle
M6 25 12 17 8 25 2.5 10 15 5 5 7
20 8470-602BG 8470-702BG
M8 32 15.5 19 10 33 3.2 12 20 6 6 8
42 8470-604BG 8470-704BG
M10 40 19 23 13 41.5 4 15 25 7 9 10 85 8470-606BG 8470-706BG
M12 50 24 31 16 51 5 20 30 8 8 13 157 8470-608BG 8470-708BG
D D1 D2 D3 D4 H H1 L1 L2 L3 L4 S
(g) WDS No.
Steel Spindle
WDS No.
Stainless Steel
Spindle
M6 25 12 17 8 25 2.5 10 15 5 5 7
20 8470-602PG 8470-702PG
M8 32 15.5 19 10 33 3.2 12 20 6 6 8
42 8470-604PG 8470-704PG
M10 40 19 23 13 41.5 4 15 25 7 9 10 85 8470-606PG 8470-706PG
M12 50 24 31 16 51 5 20 30 8 8 13 157 8470-608PG 8470-708PG
'
'
/
/
/
'
'
'
+
+
/
6SDQQHU IODW 6
'
'
/
/
/
'
'
'
+
+
/
6SDQQHU IODW 6
'
'
/
/
/
'
'
'
+
+
/
6SDQQHU IODW 6
'
'
/
/
/
'
'
'
+
+
/
6SDQQHU IODW 6
ZP
303
RAL
7021
ZP
303
RAL
7035
