SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-69
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukBlack Grey - RAL 7021
Wing Grip - Male
WDS 8460
MATERIAL
-
Body - Thermoplastic
Screw- Steel - zinc plated
Screw - Stainless Steel - 303 S31
D
D1
A
B
H
H1
L
(g)
WDS No.
Steel Screw
WDS No.
Stainless
Steel Screw
M5
14
50
5
24
11.5
15
15
8460-402BG 8460-502BG
M5
14
50
5
24
11.5
20
16
8460-404BG 8460-504BG
M6
14
50
5
24
11.5
20
17
8460-406BG 8460-506BG
M6
14
50
5
24
11.5
30
20
8460-408BG 8460-508BG
M6
14
50
5
24
11.5
40
22
8460-410BG 8460-510BG
M8
14
50
5
24
11.5
20
22
8460-412BG 8460-512BG
M8
14
50
5
24
11.5
30
26
8460-414BG 8460-514BG
M8
14
50
5
24
11.5
40
30
8460-416BG 8460-516BG
M8
21
75
7
35
16.5
20
42
8460-418BG 8460-518BG
M8
21
75
7
35
16.5
30
46
8460-420BG 8460-520BG
M8
21
75
7
35
16.5
40
50
8460-422BG 8460-522BG
M10
21
75
7
35
16.5
20
46
8460-424BG 8460-524BG
M10
21
75
7
35
16.5
30
52
8460-426BG 8460-526BG
M10
21
75
7
35
16.5
40
58
8460-428BG 8460-528BG
M10
21
75
7
35
16.5
50
65
8460-430BG 8460-530BG
%
'
'
+ /
$
+
ZP
303
RAL
7021
