SECTION 5 - HAND KNOBS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk5-72
WDS
www.wdsltd.co.ukCadmium Yellow - RAL 1021
D
D1
A
B
H
H1
L
(g)
WDS No.
Steel Screw
WDS No.
Stainless
Steel Screw
M5
14
50
5
24
11.5
15
15
8460-402CY 8460-502CY
M5
14
50
5
24
11.5
20
16
8460-404CY 8460-504CY
M6
14
50
5
24
11.5
20
17
8460-406CY 8460-506CY
M6
14
50
5
24
11.5
30
20
8460-408CY 8460-508CY
M6
14
50
5
24
11.5
40
22
8460-410CY 8460-510CY
M8
14
50
5
24
11.5
20
22
8460-412CY 8460-512CY
M8
14
50
5
24
11.5
30
26
8460-414CY 8460-514CY
M8
14
50
5
24
11.5
40
30
8460-416CY 8460-516CY
M8
21
75
7
35
16.5
20
42
8460-418CY 8460-518CY
M8
21
75
7
35
16.5
30
46
8460-420CY 8460-520CY
M8
21
75
7
35
16.5
40
50
8460-422CY 8460-522CY
M10
21
75
7
35
16.5
20
46
8460-424CY 8460-524CY
M10
21
75
7
35
16.5
30
52
8460-426CY 8460-526CY
M10
21
75
7
35
16.5
40
58
8460-428CY 8460-528CY
M10
21
75
7
35
16.5
50
65
8460-430CY 8460-530CY
Wing Grip - Male
WDS 8460
MATERIAL
-
Body - Thermoplastic
Screw- Steel - zinc plated
Screw - Stainless Steel - 303 S31
%
'
'
+ /
$
+
RAL
1021
ZP
303
