sales@wdsltd.co.ukGrip Ball
WDS 8470
MATERIAL
-
Body - Thermoplastic
Screw - Steel - zinc plated
Screw - Stainless Steel - 303 S31
Traffic Red - RAL 3020
D
D1
D2
D3
H
H1
L
(g)
WDS No.
Steel Screw
WDS No.
Stainless Steel
Screw
M6
25
12
17
25
2.5
15
20
8470-402TR 8470-502TR
M6
25
12
17
25
2.5
20
21
8470-404TR 8470-504TR
M6
25
12
17
25
2.5
25
22
8470-406TR 8470-506TR
M6
25
12
17
25
2.5
30
24
8470-408TR 8470-508TR
M8
32
15.5
19
33
3.2
20
36
8470-410TR 8470-510TR
M8
32
15.5
19
33
3.2
25
38
8470-412TR 8470-512TR
M8
32
15.5
19
33
3.2
30
40
8470-414TR 8470-514TR
M8
32
15.5
19
33
3.2
40
44
8470-416TR 8470-516TR
M10
40
19
23
41.5
4
20
63
8470-418TR 8470-518TR
M10
40
19
23
41.5
4
30
69
8470-420TR 8470-520TR
M10
40
19
23
41.5
4
40
75
8470-422TR 8470-522TR
M10
50
24
31
51
5
20
91
8470-424TR 8470-524TR
M10
50
24
31
51
5
30
97
8470-426TR 8470-526TR
M10
50
24
31
51
5
40
103 8470-428TR 8470-528TR
M12
50
24
31
51
5
20
106 8470-430TR 8470-530TR
M12
50
24
31
51
5
30
115 8470-432TR 8470-532TR
M12
50
24
31
51
5
40
123 8470-434TR 8470-534TR
'
'
'
+
+
'
/
'
'
'
+
+
'
/
ZP
303
RAL
3020
