SECTION 16 - CONVEYOR COMPONENTS & ACCESSORIES
WDS
WDS
www.wdsltd.co.uk16-21
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk'
'
'
+
+
+
%
)
'
<
Note: When using stainless balls, reduce load capacity by 33%
Note: When using stainless balls, reduce load capacity by 33%
D
D1
D2
H
H1
H2
Fixing Hole
+1.0/+1.5
Load Capacity
(kg)
(g)
WDS No.
Steel
WDS No.
Stainless Steel
15.88 32 24.5 21.0 10.0
4
24
17
50
569-215 569-615
22.22 45 35.8 27.7 9.0
3
36
50
126
569-222 569-622
30
.00 55 45.0 37.0 13.84
45
100
320
569-230 569-630
Ball Dia
mm
Body Dia
D
mm
Fitted Height
Y
mm
Ref
B
mm
Flange Dia
F
mm
Load Capacity
kg
(g)
WDS No.
Steel Balls
15
24
9.5
11.5
31
50
55
570-701
22
36
9.8
20.7
45
180
210
570-702
30
45
13.8
23.0
55
350
370
570-703
45
62
19.0
34.5
75
600
1030
570-704
Ball Dia
mm
Body Dia
D
mm
Fitted Height
Y
mm
Ref
B
mm
Flange Dia
F
mm
Load Capacity
kg
(g)
WDS No.
Stainless
Steel Balls
15
24
9.5
11.5
31
35
55
570-701A
22
36
9.8
20.7
45
126
210
570-702A
30
45
13.8
23.0
55
245
370
570-703A
45
62
19.0
34.5
75
420
1030
570-704A
Ball Transfer Unit
- Light Duty, with
Clip
WDS 569
MATERIAL
-
Body - Carbon Steel - Zinc
Plated or 304 Stainless Steel
Ball - Steel 9Cr18Mo or 402
Stainless Steel
ZP
Ball Transfer Unit
- Medium Duty
WDS 570
MATERIAL
-
Body - Case Hardened Steel
Housing - Electrophorectic
Finish
Ball - Steel 9Cr18Mo or
402 Stainless Steel
Note: No seal fitted to 570-701 or
570-701A
