Round Tube - Type R
WDS 12186
MATERIAL -
Steel with Nylon Sleeve
B Min (Ø) B Max (Ø) (g) WDS No.
19 21.5 50 12186-190R
21.5 24 55 12186-215R
24 27 60 12186-240R
27 30 65 12186-270R
31 35 70 12186-310R
0
&DSKHDG VFUHZ
,GHDO VROXWLRQ IRU PRXQWLQJ
EROW KROH ILWWLQJ FDVWRUV WR
URXQG KROORZ WXEH
Square Tube - Type S
WDS 12186
MATERIAL -
Steel with Nylon Sleeve
B Min (AFSq) B Max (AFSq) (g) WDS No.
21.5 24 55 12186-215S
24 27 60 12186-240S
27 30 65 12186-270S
32 35 70 12186-320S
36 40 80 12186-360S
% 0
&DSKHDG VFUHZ
,GHDO VROXWLRQ IRU PRXQWLQJ
EROW KROH ILWWLQJ FDVWRUV WR
VTXDUH KROORZ WXEH
Castor
Hollow tube
WDS 12186
WDS 12186
Example
Castor
Hollow tube
WDS 12186
WDS 12186
Example
