Joints - Plain
Bearing
WDS 553
MATERIAL
-
Joint yokes - 530M40 Alloy steel
locally hardened and tempered
around the bearings.
Spider pins - 708M20
Molybdenum Chrome steel
hardened and tempered.
MAX RPM = 1500
A (H8)
B
L
W (JS9)
T
X
Y
Max Torque
Nm
*Gaiter
WDS No.
(g)
WDS No.
8
16
36
2
9
4x14 M4x4
10
554-016
38
553-208
10
20
42
3
11.4 4x18 M4x5
22
554-020
69
553-210
12
23
52
4
13.8 4x20 M6x5
40
554-023
105
553-212
16
30
74
5
18.3 5x28 M6x6
82
554-030
261
553-216
20
36
87
6
22.8 6x35 M6x8
153
554-036
431
553-220
25
44
105
8
28.3 8x40 M8x8
302
554-044
771
553-225
/
%
:
$
7
;
<
.(<:$<(' %27+ (1'6
'2:(/ 3,1 ; 6833/,(' 2))
6&5(: < 6833/,(' 2))
Universal Cardan
Joints - Needle
Roller Bearing
WDS 553
MATERIAL
-
Joint Yokes = 530M40 Alloy steel
Needle Roller Bearing
X - Roll Pin DIN 1481 (2 off
supplied)
Y - Screw DIN 916 (2 off
supplied)
MAX RPM = 3000
A (H7)
B
L
W (JS9)
T
X
Y
Max Torque
Nm
(g)
WDS No.
14
28
60
5
16.3
5x28
M6x6
68
184
553-314
19
36
78
6
21.8
6x35
M6x8
176
403
553-319
24
42
82
8
27.3
8x40
M8x8
256
556
553-324
28
50
108
8
31.3
8x50
M8x10
328
1025 553-328
/
%
:
$
7
;
<
.(<:$<(' %27+ (1'6
'2:(/ 3,1 ; 6833/,(' 2))
6&5(: < 6833/,(' 2))
KEYWAYED BOTH ENDS
ROLL PIN ‘X’ SUPPLIED (2 OFF)
SCREW ‘Y’ SUPPLIED (2 OFF)
KEYWAYED BOTH ENDS
ROLL PIN ‘X’ SUPPLIED (2 OFF)
SCREW ‘Y’ SUPPLIED (2 OFF)
NOTE: Use a Gaiter for dusty
environments.*
