SECTION 18 - UNIVERSAL JOINTS
WDS
WDS
www.wdsltd.co.uk18-3
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukUniversal Joint
- Plain Bearing
Double Jointed
WDS 555
MATERIAL
-
Joint yokes = 530M40 Alloy steel
locally hardened and tempered
around the bearings.
Spider pins = 708M20
Molybdenum Chrome steel
hardened and tempered.
Plain Bearing
MAX RPM = 1500
X - Dowel pin DIN 1481 (2 off
supplied)
Y - Screw DIN 916 (2 off
supplied)
A (H8)
B
L
W (JS9)
T
X
Y
Max Torque
Nm
(g)
WDS No.
8
16
72
2
9
4x14
M4x4
8
83
555-208
10
20
84
3
11.4
4x18
M4x5
17
153
555-210
12
23
104
4
13.8
4x20
M6x5
30
240
555-212
16
30
148
5
18.3
5x28
M6x6
62
597
555-216
20
36
174
6
22.8
6x35
M6x8
116
1002 555-220
25
44
210
8
28.3
8x40
M8x8
230
1817 555-225
B
L
A
W
T
KEYWAYED BOTH ENDS
DOWEL PIN 'X' SUPPLIED (2 OFF)
SCREW 'Y' SUPPLIED (2 OFF)
