SECTION 19 - TOGGLE CLAMPS & ACCESSORIES
WDS
WDS
www.wdsltd.co.uk19-27
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukHeavy Duty Push/
Pull Clamp
WDS 4041
MATERIAL
-
Piston and handle - Steel
Body Malleable iron
To achieve full stoke handle swings through 180°, provision must be made in the fixture to accommodate the handle and its mounting block
B B1 D D1 D2 H H1 H2 L L1 L2 L3 L4 L5 S
Holding
Force (kg)
(kg) WDS No.
47 33.3 5.5 M8x30 14 140 12 22 89 38 25 36.5 -
70 32 600
0.60 4041-201
62 41 8.6 M10x40 20 235 18 32 133 55 8 35 41 100 50 1200
1.70 4041-202
80 54 10.3 M12x60 25 285 22 40 193 102 12 45 45 130 75 2500
4.20 4041-203
84 57 10.3 M16x60 30 380 28 50 247 138 12 70 70 180 100 5000
7.20 4041-204
/
/
'
+
/
6
+DQGOH PD\ EH
UHYHUVHG LQ LWV
PRXQWLQJ EORFN
/
/ /
'
%
+
%
+
'
6 6WURNH
