Miniclamp
Woodworking
SF-1200M
Technical Information
Mechanical Operation Maximum loading 6kg
300mm from Ball Centre at 45’ degrees
The SF-1200M HydraClamp is ideal as a wood working
and wood carving clamp
One motion of the operating lever locks the work in any
desired position. It is the ideal tool for the assembly of all light components and will hold any fitment or
jig which can be drilled and tapped for mounting direct on the thread.
To reset preload, or adjust handle position, it is only necessary to slacken the adjustment lock screw in
the side of the body, reposition the nut plate and lock in required new position.
A
B
C
Description
WDS No.
125
108
97
BASE UNIT ONLY
SF-1200M
125
108
97
BASE UNIT fitted with 50mm Face Plate (SF-1279A)
SF-1200A
125
108
97
BASE UNIT fitted with 75mm Face Plate (SF-1279B)
SF-1200B
125
108
97
BASE UNIT fitted with 100mm Face Plate (SF-1279C)
SF-1200C
125
108
97
BASE UNIT fitted with 120mm Face Plate (SF-1276)
SF-1200D
D
D1
D2
H
(g)
WDS No.
M12
120
89
8
684
SF-1276
A
C
B
(g)
WDS No.
50
8
32
38
SF-1279A
75
8
55
91
SF-1279B
100
8
80
165
SF-1279C
Face Plate for
SF-1200M,
SF-1310M
Face Plate for
SF-1200M,
SF-1310M
SF-1276
SF-1279
MATERIAL
-
220M07 Chemical Black Finish
Ideal for Woodworking applications
MATERIAL
-
Aluminium
Ideal for Woodworking applications
50
96
123
27
M12 x 1.75
9.5
50
76
115
M12 LOCK NUT
SUPPLIED
32
120°
94 P.C.D.
3 x 7mm EQUALLY
SPACED
1200M
'
' SFG
