SECTION 21 - SPENCER FRANKLIN HYDRACLAMP, HYDRAULICS
AND PNEUMATICS WDS
WDS
21-7 & 0845 606 66 77 • : • *
Hydraclamp Major
Type
SF-1500M
TECHNICAL INFORMATION -
Hydraulic Operation MAJOR TYPE
1500M
Maximum loading 325kg 300mm
from Ball Centre at 45 degrees
The Major model Hydraclamp
provides a really robust positioner
suitable for horizontal or vertical
mounting.
Tightening is effected by a handwheel
with final locking by tommy bar.
A pre-load sleeve is fitted to enable
any desired degree of sustained
pressure to be applied and
maintained.
A B C D E F G H K L (kg) Seal Kit WDS No.
96.5 378 178 145 127 235 17.5 159 22 94 37.5 SF-4778 SF-1500M
A B C Pedal Type Clamp type Seal Kit forClamp (kg) WDS No.
113.4 179 36 Standard SF-1500M SF-4778 37.5 SF-1501M
113.4 179 36 Covered SF-1500M SF-4778 37.5 SF-1502M
Major Hydraclamp
Foot Operation
SF-1501M
TECHNICAL INFORMATION -
Type 1501M Major Foot Operation
Both hands are free to manipulate
the work mounted on Major
Hydraclamp by the direct coupling
of an air-hydraulic booster. This
gives complete control from a foot
pedal which can be placed at any
convenient position for right or left
foot. Two independent safety factors
are incorporated. They ensure that
the work will stay locked in the event
of sudden failure of the air supply or
under a pre-determined degree of
sustained pressure if the foot pedal is
operated in error
Max air pressure 4 bar
(
*
( +
+ROHV HTXLVSDFHG DV VKRZQ
KROHV RQ PP 3&'
KROHV RQ PP 3&'
0RXQWLQJ KROHV [
'ULOO DQG F ERUH IRU 0
FDSVFUHZV RQ PP 3&'
)RXU 0 [ [ GHHS
KROHV RQ EDOO DUP IDFH
$
)
&
%
.
'
/
$
% &
%63 ,1/(7
6(( 6) 0
IRU GHWDLOV
6833/,(' &203/(7( :,7+
67$1'$5' )227 3('$/
$1' +26(
Re fer to page 21-47 for Oil Grades
Re fer to page 21-47 for Oil Grades
