www.wdsltd.co.ukScrew Pump
SF-OE00401-
OE00404
A
F
C
P
H
BREATHER FILTER
1/8" B.S.P. PLUG
B
E
N
K M
L
D
1/4" B.S.P. PORT
G
H
J A/F
OE00401
Piston
Dia
Stroke A B
C
D E F G H J K L M N P R S WDS No.
25 43 94 65 40 12 33 32 75 12 24 7.5 53.5 18.5 50 12.5 17.5 8.5 SF-OE00401
25 86 137 65 40 12 33 32 118 12 24 7.5 96.5 18.5 50 12.5 17.5 8.5 SF-OE00402
25 43 98 36 M38 x 1.5 12 32 13 56 14 24 -
-
-
-
-
-
-
SF-OE00403
25 86 141 36 M38 x 1.5 12 32 13 141 14 24 -
-
-
-
-
-
-
SF-OE00404
Displacement cm³
Displacement per turn
of Handwheel cm³
WDS No.
21
0.74
SF-OE00401
42
0.74
SF-OE00402
21
0.74
SF-OE00403
42
0.74
SF-OE00404
Maximum Operating Pressure = 350 Bar
Torque Required to Produce 275 Bar Approx 35N
Re
fer to page 21-46 & 21-47 for more
technical information
