SECTION 21 -
SPENCER FRANKLIN HYDRACLAMP, HYDRAULICS
AND PNEUMATICS
WDS
WDS
www.wdsltd.co.uk21-37
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukCapstan Pump
SF-OE00411-
OE00412
G
H
F
E
M HOLES 2 - OFF
B
K
J
A
L
C
MOUNTING CLAMP
D PORTS 2-OFF
OE00411
A B C D E
F
G H J
K
L
M WDS No.
Clamp Only
WDS No.
150.8 50.8 25.4
1
⁄
8
" 85.7 60.3 82.5 31.75 63.5 44.5 12.7 10.3 SF-OE00411 SF-OE50010
200 60 65 ¼" 131 71.5 91 40 75 45 15 10.3 SF-OE00412 SF-OE50011
Output for full travel
cm³
Output for one complete
turn of Handwheel cm³
Weight kg WDS No.
25.84
1.84
2
SF-OE00411
127.6
2.95
3.74
SF-OE00412
Maximum Operating Pressure = 270 Bar (3000 P.S.I)
ALL CAPSTANS ARE SUPPLIED WITH MOUNTING CLAMP AS STANDARD
Re
fer to page 21-46 & 21-47 for more
technical information
