SECTION 26 - NUTS, WASHERS, SCREWS & STUDS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk26-10
WDS
www.wdsltd.co.uk'
'
+
' 6WXG 6L]H
Jig Washer
WDS 400
MATERIAL
-
Steel, BS.970 Gr.220M07
Surface hardened
Chemical black finish
See 802 Series for this part in
Stainless Steel
D
D1
D2
H
(g)
WDS No.
Metric
Inch
M4
-
10
4.5
1.5
1
400-2004
M5
2BA
12
5
2.5
2
400-2005
M6
1
⁄
4
16
6.7
2.5
3
400-201
M8
5
⁄
16
19
8.5
3
6
400-202
M10
3
⁄
8
22
10.5
3
7
400-203
M10
3
⁄
8
25
10.5
5
16
400-204
M12
1
⁄
2
28
13
3
11
400-205
M14
-
28
14.5
3
13
400-206
M16
5
⁄
8
32
16.5
3
14
400-207
M16
5
⁄
8
38
16.5
6.5
45
400-208
M20
3
⁄
4
38
20.5
4
25
400-209
M24
1
50
27
5
52
400-211
'
'
+
' 6WXG 6L]H
D = Stud Size
Plain Washer -
Stainless
WDS 802
MATERIAL
-
Stainless Steel
BS 970 Gr 316S11
See 400 Series for this part
in Steel
D
D1
D2
H
(g)
WDS No.
M6
16
6.5
2.5
3
802-206
M8
20
8.5
2.5
5
802-208
M10
25
10.5
3
7
802-210
M12
30
12.5
3.5
16
802-212
M16
35
16.5
4
23
802-216
D = Stud Size
316
