SECTION 26 - NUTS, WASHERS, SCREWS & STUDS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk26-12
WDS
www.wdsltd.co.ukC-Washer
Captive C-Washer
WDS 402
WDS 403
MATERIAL
-
Steel, BS.970 Gr. 220M07
Case hardened
Chemical black finish
See 804 Series for this part in
Stainless Steel
MATERIAL
-
Steel, BS.970 Gr.070M20
Case hardened
Chemical black finish
'
'
+
' 678' 6,=(
D = Stud Size
D
D1
H
(g) WDS No.
Metric Inch
M4
-
16
3
5 402-2004
M5
2BA 30
5
20 402-2005
M6
1
⁄
4
20
5
7 402-201
M6
1
⁄
4
25
5
10 402-202
M6
1
⁄
4
32
5
25 402-203
M8
5
⁄
16
35
6.5
30 402-204
M8
5
⁄
16
38
6.5
35 402-205
M8
5
⁄
16
45
6.5
40 402-206
M10
3
⁄
8
32
6.5
25 402-207
M10
3
⁄
8
38
6.5
30 402-208
M10
3
⁄
8
45
8
40 402-209
D
D1
H
(g) WDS No.
Metric Inch
M10
3
⁄
8
50
8
50 402-210
M10
3
⁄
8
55
8
65 402-211
M10
3
⁄
8
63
9.5
80 402-212
M12
1
⁄
2
50
9.5
120 402-214
M12
1
⁄
2
63
9.5
130 402-215
M12
1
⁄
2
75
11
140 402-216
M16
5
⁄
8
54
9.5
125 402-219
M16
5
⁄
8
75
12.5 140 402-220
M20
3
⁄
4
63
11
200 402-221
M20
3
⁄
4
75
12.5 220 402-222
M24
1
75
12.5 200 402-226
D A D1 H R R1
(g) WDS No.
M5 19 8 6 12.5 8 21 403-2005
M6 19 8 6 12.5 8 21 403-201
M8 22 8 6 16 8 39 403-202
M10 25 8 6 19 10 56 403-203
M12 32 10 10 22 13 106 403-204
M16 38 10 10 25 14 335 403-206
M20 45 12 12 32 16 300 403-207
Metric
D A D1 H R R1
(g) WDS No.
5
⁄
16
22
5
⁄
16
0.250" 16 8 40 403-03
3
⁄
8
25.4
3
⁄
8
0.250" 19 10 50 403-04
3
⁄
8
34.9
3
⁄
8
0.250" 19 10 70 403-11
1
⁄
2
32
3
⁄
8
0.313" 22 13 100 403-05
1
⁄
2
38
3
⁄
8
0.313" 22 13 120 403-12
5
⁄
8
38
1
⁄
2
0.375" 25 14 165 403-06
3
⁄
4
44.5
1
⁄
2
0.500" 32 16 330 403-07
Inch
$
+
'
5
5
5$1*(
PP
PP
' 678' 6,=(
