SECTION 2 - LOCATION & POSITIONING
WDS
WDS
www.wdsltd.co.uk2-13
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukL Handle Quick
Release Pins
WDS 952
A Nominal D1A (Max) A (Min)
L B +/-0.25 C+/-1.0 D
E
F
G
H
(g)
WDS No.
6
5.96
5.92
25
7.1
7
6
12
22.5
32
19
22 952-206025
6
5.96
5.92
30
7.1
7
6
12
22.5
32
19
24 952-206030
6
5.96
5.92
40
7.1
7
6
12
22.5
32
19
26 952-206040
6
5.96
5.92
50
7.1
7
6
12
22.5
32
19
28 952-206050
6
5.96
5.92
60
7.1
7
6
12
22.5
32
19
30 952-206060
8
7.96
7.92
25
9.4
8
6
12
22.5
32
19
28 952-208025
8
7.96
7.92
30
9.4
8
6
12
22.5
32
19
30 952-208030
8
7.96
7.92
40
9.4
8
6
12
22.5
32
19
34 952-208040
8
7.96
7.92
50
9.4
8
6
12
22.5
32
19
38 952-208050
8
7.96
7.92
60
9.4
8
6
12
22.5
32
19
42 952-208060
8
7.96
7.92
80
9.4
8
6
12
22.5
32
19
49 952-208080
10
9.96
9.92
25
11.9
9
7
14
25
37
23
46 952-210025
10
9.96
9.92
30
11.9
9
7
14
25
37
23
49 952-210030
10
9.96
9.92
40
11.9
9
7
14
25
37
23
54 952-210040
10
9.96
9.92
50
11.9
9
7
14
25
37
23
62 952-210050
10
9.96
9.92
60
11.9
9
7
14
25
37
23
67 952-210060
10
9.96
9.92
80
11.9
9
7
14
25
37
23
77 952-210080
12
11.96
11.92
25
14.4
10
10
18
30
43
25
72 952-212025
12
11.96
11.92
30
14.4
10
10
18
30
43
25
77 952-212030
12
11.96
11.92
40
14.4
10
10
18
30
43
25
85 952-212040
12
11.96
11.92
50
14.4
10
10
18
30
43
25
92
952-212050
12
11.96
11.92
60
14.4
10
10
18
30
43
25
100 952-212060
12
11.96
11.92
80
14.4
10
10
18
30
43
25
116
952-212080
F
D
A
E
H
G
B
L
C
+0.5/0.0mm
MATERIAL
-
Black cast aluminium L-handle*
Blue anodised aluminium button
17-4PH Stainless Steel Spindle
Includes hole and ring for easy
attachment of optional chain or
lanyard.
*Other styles available
