SECTION 2 - LOCATION & POSITIONING
WDS
WDS
www.wdsltd.co.uk2-15
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukDetent Pin - 316
Stainless Steel
Metric
WDS 957
MATERIAL
-
Pin - 316 Stainless Steel
Ball - 316 Stainless Steel
D
L1
L
E
+0.5
-0.0
D (Nominal)
D
E
L
L1
(g)
WDS No.
6
5.96/5.86
6.45
15
8.7/7.2
10
957-20615
6
5.96/5.86
6.45
20
8.7/7.2
11
957-20620
6
5.96/5.86
6.45
30
8.7/7.2
13
957-20630
6
5.96/5.86
6.45
40
8.7/7.2
15
957-20640
6
5.96/5.86
6.45
50
8.7/7.2
18
957-20650
6
5.96/5.86
6.45
60
8.7/7.2
20
957-20660
8
7.96/7.86
8.58
20
9.1/7.6
18
957-20820
8
7.96/7.86
8.58
30
9.1/7.6
22
957-20830
8
7.96/7.86
8.58
40
9.1/7.6
26
957-20840
8
7.96/7.86
8.58
50
9.1/7.6
30
957-20850
8
7.96/7.86
8.58
60
9.1/7.6
34
957-20860
8
7.96/7.86
8.58
70
9.1/7.6
38
957-20870
8
7.96/7.86
8.58
80
9.1/7.6
41
957-20880
10
9.96/9.86
10.79
40
9.9/8.4
38
957-21040
10
9.96/9.86
10.79
60
9.9/8.4
51
957-21060
10
9.96/9.86
10.79
80
9.9/8.4
64
957-21080
10
9.96/9.86
10.79
100
9.9/8.4
76
957-210100
Detent Pin - 316
Stainless Steel,
Imperial
WDS 957
MATERIAL
-
Pin - 316 Stainless Steel
Ball - 316 Stainless Steel
D
L1
L
E
+0.02"
-0.00"
D (Nominal)
D
E
L
L1
(g)
WDS No.
1/4"
0.249/0.245"
0.28"
0.5"
0.344/0.284"
10
957-10205
1/4"
0.249/0.245"
0.28"
0.8"
0.344/0.284"
12
957-10208
1/4"
0.249/0.245"
0.28"
1.0"
0.344/0.284"
13
957-10210
1/4"
0.249/0.245"
0.28"
1.5"
0.344/0.284"
16
957-10215
1/4"
0.249/0.245"
0.28"
2.0"
0.344/0.284"
20
957-10220
1/4"
0.249/0.245"
0.28"
2.5"
0.344/0.284"
22
957-10225
1/4"
0.249/0.245"
0.28"
3.0"
0.344/0.284"
26
957-10230
5/16"
0.311/0.307"
0.36"
0.8"
0.359/0.299"
17
957-10408
5/16"
0.311/0.307"
0.36"
1.0"
0.359/0.299"
20
957-10410
5/16"
0.311/0.307"
0.36"
1.5"
0.359/0.299"
24
957-10415
5/16"
0.311/0.307"
0.36"
2.0"
0.359/0.299"
30
957-10420
5/16"
0.311/0.307"
0.36"
2.5"
0.359/0.299"
34
957-10425
5/16"
0.311/0.307"
0.36"
3.0"
0.359/0.299"
39
957-10430
