SECTION 2 - LOCATION & POSITIONING
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk2-16
WDS
www.wdsltd.co.ukHeavy Duty
Stainless Steel
Detent Pins
WDS 956
Pin Diameter
A
Grip Length L
(mm)
B C D E
Double Shear
Resistance
min (N)
Pin Pullout
Min Force
(N)
Hole Dia
(Max)
Hole Dia
(Min)
(g) WDS No.
6
15
7 8.1 9.5 12.7 35650
17.8
6.1
6
15 956-06015
6
20
7 8.1 9.5 12.7 35650
17.8
6.1
6
15 956-06020
6
30
7 8.1 9.5 12.7 35650
17.8
6.1
6
20 956-06030
6
40
7 8.1 9.5 12.7 35650
17.8
6.1
6
20 956-06040
6
50
7 8.1 9.5 12.7 35650
17.8
6.1
6
25 956-06050
6
60
7 8.1 9.5 12.7 35650
17.8
6.1
6
25 956-06060
8
20
9.5 8.3 11.1 12.7 63790
17.8
8.1
8
20 956-08020
8
30
9.5 8.3 11.1 12.7 63790
17.8
8.1
8
25 956-08030
8
40
9.5 8.3 11.1 12.7 63790
17.8
8.1
8
30 956-08040
8
50
9.5 8.3 11.1 12.7 63790
17.8
8.1
8
35 956-08050
8
60
9.5 8.3 11.1 12.7 63790
17.8
8.1
8
35 956-08060
8
80
9.5 8.3 11.1 12.7 63790
17.8
8.1
8
45 956-08080
10
40
12 9.8 12.7 12.7 100060
17.8
10.1
10
45 956-10040
10
60
12 9.8 12.7 12.7 100060
17.8
10.1
10
55 956-10060
10
80
12 9.8 12.7 12.7 100060
17.8
10.1
10
70 956-10080
10
100
12 9.8 12.7 12.7 100060
17.8
10.1
10
80 956-10100
A
E
D
L
Grip Length
B
C
MATERIAL
-
Body - 17-4 PH Heat treated
stainless steel
Head and Spring - 304 Stainless
Steel
Balls - 440C Stainless Steel
Collar - 303 Stainless Steel
Includes hole and ring for easy
attachment of optional chain or
lanyard.
*Other styles available
