SECTION 2 - LOCATION & POSITIONING
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk2-14
WDS
www.wdsltd.co.ukPush Button
Handle Quick
Release Pins
WDS 954
Pin Diameter
Grip Length L
(mm)
A (Max) A (Min) B +/-0.25 C+/-1.0 D E
F
G H
(g) WDS No.
6
25
5.96 5.92 6.99
7
6.5 20.5 16 12
23 17 954-106025
6
30
5.96 5.92 6.99
7
6.5 20.5 16 12
23
18 954-106030
6
40
5.96 5.92 6.99
7
6.5
20.5 16 12
23
20 954-106040
6
50
5.96 5.92 6.99
7
6.5
20.5 16 12
23
22 954-106050
6
60
5.96 5.92 6.99
7
6.5
20.5 16 12
23
24 954-106060
8
25
7.96 7.92 9.42
8
6.5
20.5 17 12
24
24 954-108025
8
30
7.96 7.92 9.42
8
6.5
20.5 17 12
24
26 954-108030
8
40
7.96 7.92 9.42
8
6.5
20.5 17 12
24
29 954-108040
8
50
7.96 7.92 9.42
8
6.5
20.5 17 12
24
32 954-108050
8
60
7.96 7.92 9.42
8
6.5
20.5 17 12
24
37 954-108060
8
70
7.96 7.92 9.42
8
6.5
20.5 17 12
24
40 954-108070
10
25
9.96 9.92 11.96
9
7.5
25.5 20 15
28 40 954-110025
10
30
9.96
9.92 11.96
9
7.5
25.5 20 15
28 42 954-110030
10
40
9.96 9.92 11.96
9
7.5
25.5 20 15
28
48 954-110040
10
50
9.96 9.92 11.96
9
7.5
25.5 20 15
28
54 954-110050
10
60
9.96
9.92 11.96
9
7.5
25.5 20 15 28 60 954-110060
10
70
9.96 9.92 11.96
9
7.5
25.5 20 15 28 66 954-110070
L
Grip Length
F
H
D
C
G
A
B
E
MATERIAL
-
Black turned aluminium alloy
6061 T6 handle
Blue anodised aluminium button
17-4 PH Stainless Steel Body
Includes hole and ring for easy
attachment of optional chain or
lanyard.
*Other styles available
