SECTION 2 - LOCATION & POSITIONING
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk2-28
WDS
www.wdsltd.co.ukSpring Locator
WDS 675
MATERIAL
WDS 675-101 & WDS 675-102:
Heavy gauge steel precision
ground and hardened casing
and pin
Casing
-
BS.817M40T
MATERIAL
-
WDS 675-301
Heavy Gauge Steel
For applications where high
precision locating is not
required the 675-301 may be
more appropriate.
D1
+0 -0.05
D2
+0 -0.05
B1
B2
H1
Stroke
(g)
WDS No.
20
12
16
58
45
16
150
675-101
40
25
32
116
90
32
1100
675-102
D1
D2
B1
B2
H1
Stroke
(g)
WDS No.
20
10
13
58
45
13
140
675-301
+
%
%
'
'
Spring Locator
WDS 675
MATERIAL
-
Heavy gauge steel precision
ground
and hardened pin
Spring loaded high precision
locating pin.
L1
L2
L3
D1
D2
+0 -0.05
B1
B2
B3
(g) WDS No.
62
38
8
2 x 6.3
16
33.5
84
190
360 675-201
%
'
%
'
/
/
/
%
Spring loaded locators are ideally suited for high precision location
Horizontal
Mounting Bracket
for Cam Action
Indexing Plungers
WDS 675
MATERIAL
-
Aluminium 3.2163 - Black
Anodized
A
B
C
D
D1
E
F
H
H1
(g)
WDS No.
M16 x 1.5
46
15
5.5
10
5.5
32
29
17
74
675-616B
M20 x 1.5
46
15
5.5
10
5.5
32
29
17
70
675-620B
H
B
E
A
H1
C
D1
D
F
