SECTION 2 - LOCATION & POSITIONING
WDS
WDS
www.wdsltd.co.uk2-33
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSpring Loaded
Index Bolt
Standard Type
WDS 654
MATERIAL
-
Steel body and pin (pin
hardened)
Chemical black finish
Black thermoplastic knob
Supplied complete with lock nut
See 826 Series for this part in
Stainless Steel
P = Spring force initial pressure
approx. (kgf)
P1 = Spring force final pressure
approx. (kgf)
D D1
D2
L
L1
L2 L3 L4 S S1 P P1
(g)
WDS No.
5
21 M10 x 1 47 17
5
7 33 17 13 0.5 1.2
26
654-201
6
25 M12 x 1.5 56 20
6
8 39 19 14 0.6 1.4
37
654-202
8
33 M16 x 1.5 74 26
8
10 51 24 19 1.5 3.6
88
654-203
10 33 M20 x 1.5 80 28 10 12 55 30 22 1.5 3.4 145
654-204
'
/ /
'
/
/
'
6 $ )
6
/
L4 - Handle Retracted
Spring Loaded
Index Bolt Parking
Type
WDS 654
MATERIAL
-
Steel body and pin (pin
hardened)
Chemical black finish
Black thermoplastic knob
Supplied complete with lock nut
See 826 Series for this part in
Stainless Steel
P = Spring force initial pressure
approx. (kgf)
P1 = Spring force final pressure
approx. (kgf)
D
D1
D2
L
L1 L2 L3 L4 S S1 P P1
(g)
WDS No.
5
21 M10 x 1 47 17 5
7 33 17 13 0.5 1.2
25
654-201P
6
25 M12 x 1.5 56 20 6
8 39 19 14 0.6 1.4
41
654-202P
8
33 M16 x 1.5 74 26 8 10 51 24 19 1.5 3.6
92
654-203P
10
33 M20 x 1.5 80 28 10 12 55 30 22 1.5 3.4 105
654-204P
'
/ /
'
/
/
'
6 $ )
6
/
L4 - Handle Retracted
