SECTION 2 - LOCATION & POSITIONING
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk2-30
WDS
www.wdsltd.co.ukCompact Spring
Loaded Index
Bolt - Red Knob
Standard Type
WDS 722
MATERIAL
-
Steel body and pin (pin hardened
Class 5.8)
Chemical black finish
Red thermoplastic knob
Supplied complete with Lock Nut
F1 = Spring force initial pressure
approx. (kgf)
F2 = Spring force final pressure
approx. (kgf)
D D1
D2
L
L1 L2
L3
L5
S
S1
F1
F2
(g)
WDS No.
3 14 M6x0.75 25.5 6 3.5
5
3
10
8
0.4 1.0
5
722-206R
4 18 M8x1.0 29.5 6
4
6
4
13 10 0.4 1.2
10
722-208R
5 21 M10x1.0 34.5 8
5
7
5
17 13 0.5 1.2
21
722-210R
6 25 M12x1.5 41.7 10
6
8
6
19 14 0.6 1.4
31
722-212R
8 33 M16x1.5 54 12
8
10
8
24 19 1.4 2.8
70
722-216R
10 33 M20x1.5 61 15 10 12 10 30 22 1.5 3.2 116
722-220R
Compact Spring
Loaded Index
Bolt - Red Knob
Parking Type
WDS 722
MATERIAL
-
Steel body and pin (pin hardened
Class 5.8)
Chemical black finish
Red thermoplastic knob
Supplied complete with Lock Nut
F1 = Spring force initial pressure
approx. (kgf)
F2 = Spring force final pressure
approx. (kgf)
D D1
D2
L
L1
L2
L3
L5
S
S1
F1
F2
(g)
WDS No.
3 14 M6x0.75 25.5 6
3.5
5
3
10
8
0.4 1.0
5
722-206RP
4 18 M8x1.0 29.5 6
4
6
4
13 10 0.4 1.2
19 722-208RP
5 21 M10x1.0 34.5 8
5
7
5
17 13 0.5 1.2
20 722-210RP
6 25 M12x1.5 41.7 10
6
8
6
19 14 0.6 1.4
29 722-212RP
8 33 M16x1.5 54 12
8
10
8
24 19 1.4 2.8
67 722-216RP
10 33 M20x1.5 61 15 10 12 10 30 22 1.5 3.2 114 722-220RP
D
D2
L2
L1 L3
L
L5
D1
S a/f S1 a/f
F1 = Initial Spring Force (kgf)
F2 = Final Spring Force (kgf)
D
D2
L2
L1 L3
L
L5
D1
S a/f S1 a/f
F1 = Initial Spring Force (kgf)
F2 = Final Spring Force (kgf)
