sales@wdsltd.co.ukStainless Steel
Shaft Collar with
Indexing Lever
WDS 827
MATERIAL
-
Collar - 304 Stainless Steel -
Natural finish
Handle Plastic-PA6
Locking Screw - Stainless Steel
(A2)
D
D1
L
H T
D2
B
JS14
D
D1
D2
B
H
L
T
(g)
WDS No.
10
20
M5
10
33
45
11
33
827-107A
12
22
M6
12
33
45
11
40
827-109A
16
25
M6
12
33
45
11
45
827-111A
16
28
M6
12
33
45
11
54
827-113A
20
32
M6
14
33
45
11
69
827-115A
22
36
M6
14
33
45
16
87
827-117A
25
40
M8
16
33
45
14
114
827-121A
30
45
M8
16
33
45
14
129
827-123A
35
56
M8
16
33
45
21
223
827-127A
40
63
M10
18
43
65
21
303
827-131A
50
80
M10
18
43
65
24
474
827-135A
Stainless Steel
Split Shaft Collar
with Indexing
Lever
WDS 827
MATERIAL
-
Collar - 304 Stainless Steel -
Natural finish
Handle Plastic-PA6
Locking Screw - Stainless Steel
(A2)
D
D1
L1
L2
H
D2
B
JS14
D
D1
D2
B
H
L1
L2
(g)
WDS No.
10
24
M3
9
46
8.5
45
44
827-310A
12
28
M4
11
48
10
45
64
827-312A
15
34
M5
13
51
12.3
45
102
827-315A
16
34
M5
13
51
12.5
45
100
827-316A
20
40
M5
15
53
15
45
140
827-320A
22
42
M5
15
53
16
45
147
827-322A
25
45
M5
15
54
17.5
45
159
827-325A
