SECTION 4 - HANDWHEELS & GRIPS WDS
& 0845 606 66 77 • : • * 4-30
WDS
D D1 S A A1 B H H1 L L1 L2 (g)
WDS No.
Insert - Reamed hole H7
WDS No.
Insert - Square hole
8 13 8 104 80 24 29 13 85.5 49 13 100 8425-202 8425-302
10 13 10 104 80 24 29 13 85.5 49 13 97 8425-204 8425-304
10 16 10 129 100 29 36 13 105 59.5 16 190 8425-208 8425-308
12 16 12 129 100 29 36 13 105 59.5 16 186 8425-210 8425-310
12 20 12 161 125 36 44 18.5 140 83.5 19.5 370 8425-212 8425-312
14 20 14 161 125 36 44 18.5 140 83.5 19.5 365 8425-214 8425-314
Crank Handle with
Foldaway
Revolving Grip
WDS 8425
MATERIAL -
Handle - Thermoplastic
Insert - Steel, chemical black
%
'
$
+
$
/
/ /
5HPRYDEOH FDS
)ROGLQJ
KDQGOH
+
+ROH ' RU6TXDUH 6
%
'
$
+
$
/
/ /
5HPRYDEOH FDS
)ROGLQJ
KDQGOH
+
+ROH ' RU6TXDUH 6
