Foldaway Revolving
Grip
WDS 8410
MATERIAL
-
Wheel - Thermoplastic
Insert - Steel, chemical black
D
H7
D1 D2 D3 D4 D5
A A1
H H1
L
L1 L2
(g) WDS No.
8
80 25 19 13 M4 30 2.5 17.5 13 75 37.5 40 100 8410-202
10 80 25 19 13 M4 30 2.5 17.5 13 75 37.5 40
97 8410-204
12 80 25 19 13 M4 30 2.5 17.5 13 75 37.5 40
94 8410-206
10 100 28 19 16 M 5 38
3
20 13 90 44 49 179 8410-208
12 100 28 19 16 M 5 38
3
20 13 90 44 49 175 8410-210
12 125 35 25 20 M 6 47.5 4 23.5 18.5 109 53 59.5 328 8410-212
14 125 35 25 20 M 6 47.5 4 23.5 18.5 109 53 59.5 322 8410-214
16 125 35 25 20 M 6 47.5 4 23.5 18.5 109 53 59.5 316 8410-216
14 160 45 25 26 M 8 62 5.6 28 18.5 144 64.5 83.5 651 8410-218
16 160 45 25 26 M 8 62 5.6 28 18.5 144 64.5 83.5 644 8410-220
'
'
$
'
'
'
+
+
$
'
/
/
/
+
Handwheel - Press
Fit
WDS 8107
MATERIAL
-
PF31 (Bakelite)
Boss - Steel, Zinc Plated
D
D1
D2
H
H1
T
(g)
WDS No.
10
80
25
49
14
35
162
8107-201
10
100
25
55
14
35
212
8107-204
10
125
25
59
14
35
270
8107-207
'
'
'
+
