SECTION 4 - HANDWHEELS & GRIPS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk4-22
WDS
www.wdsltd.co.ukHandwheel - H8
Square Hole
WDS 8177
MATERIAL
-
Aluminium - Al Si 9 Mg
Boss machined, rim machined and
polished
D
B
D1 (H8)
D2
L
L1
(g)
WDS No.
80
15
10
25
31
16
130
8177-500
100
18
10
28
33
17
300
8177-501
125
20
12
30
36
18
497
8177-502
160
23
14
40
40
20
870
8177-503
200
26
18
50
45
24
1650
8177-504
D
D1
D2
B
L1
L
Al
Handwheel - Solid
WDS 133
MATERIAL
-
Aluminium
See 8179 series for metric
aluminium handwheel
*Please note that D2 is a pilot
diameter only
D
A
B
D1
D2*
L
L1
L2
(g)
WDS No.
6" (156mm)
57
17
35
9
27
21
14
420
133-13
'
$
%
/ /
'
'
/
Al
