SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-47
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukKnurled Wheel -
Male Thread
WDS 8485
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
D
D1
D2
H
H1
L
(g)
WDS No.
Steel Screw
WDS No.
Stainless Steel
Screw
M5
40
16.5
31
13
10
16
8485-502PG 8485-602PG
M5
40
16.5
31
13
20
17
8485-504PG 8485-604PG
M5
40
16.5
31
13
40
20
8485-506PG
-
M6
40
16.5
31
13
10
17
8485-508PG 8485-608PG
M6
40
16.5
31
13
20
19
8485-510PG 8485-610PG
M6
40
16.5
31
13
40
23
8485-512PG 8485-612PG
M8
40
16.5
31
13
15
23
8485-514PG 8485-614PG
M8
40
16.5
31
13
30
29
8485-516PG 8485-616PG
M8
40
16.5
31
13
60
41
8485-518PG 8485-618PG
M8
50
18
36
15
15
26
8485-520PG 8485-620PG
M8
50
18
36
15
30
32
8485-522PG 8485-622PG
M8
50
18
36
15
60
44
8485-524PG 8485-624PG
M10
50
18
36
15
20
35
8485-526PG 8485-626PG
M10
50
18
36
15
30
41
8485-528PG 8485-628PG
M10
50
18
36
15
60
60
8485-530PG 8485-630PG
M10
63
22
41
17
20
39
8485-532PG 8485-632PG
M10
63
22
41
17
30
46
8485-534PG 8485-634PG
M10
63
22
41
17
60
64
8485-536PG 8485-636PG
M12
63
22
41
17
30
61
8485-538PG
-
M12
63
22
41
17
60
87
8485-540PG
-
/
+
+
'
'
'
Pale Grey - RAL 7035
ZP
303
RAL
7035
