SECTION 5 - HAND KNOBS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk5-50
WDS
www.wdsltd.co.ukKnurled Wheel -
Female Thread
WDS 8485
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
Black Grey - RAL 7021
D D1 D2 D3
H8
H H1
T
(g)
WDS No. Steel
Threaded Insert
WDS Steel Reamed
H8
Insert
WDS No. Stainless
Steel Insert
M5 40 16.5 -
31 13 10 12.5 8485-202BG
-
8485-402BG
M6 40 16.5 6
31 13 10 12.2 8485-204BG 8485-304BG 8485-404BG
M8 40 16.5 -
31 13 14 11.5 8485-206BG
-
8485-406BG
M8 50 18
8
36 15 14 14.5 8485-208BG 8485-308BG 8485-408BG
M10 50 18
-
36 15 14 14.1 8485-210BG
-
8485-410BG
M10 63 22 10 41 17 14 18.5 8485-212BG 8485-312BG 8485-412BG
M12 63 22
-
41 17 18 17.9 8485-214BG
-
8485-414BG
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
RAL
7021
ZP
303
Knurled Wheel -
Female Thread
WDS 8485
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
Pale Grey - RAL 7035
D D1 D2 D3
H8
H H1
T
(g)
WDS No. Steel
Threaded Insert
WDS Steel Reamed
H8
Insert
WDS No. Stainless
Steel Insert
M5 40 16.5 -
31 13 10 12.5 8485-202PG
-
8485-402PG
M6 40 16.5 6
31 13 10 12.2 8485-204PG 8485-304PG 8485-404PG
M8 40 16.5 -
31 13 14 11.5 8485-206PG
-
8485-406PG
M8 50 18
8
36 15 14 14.5 8485-208PG 8485-308PG 8485-408PG
M10 50 18
-
36 15 14 14.1 8485-210PG
-
8485-410PG
M10 63 22 10 41 17 14 18.5 8485-212PG 8485-312PG 8485-412PG
M12 63 22
-
41 17 18 17.9 8485-214PG
-
8485-414PG
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
ZP
303
RAL
7035
