SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-49
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukKnurled Wheel -
Male Thread
WDS 8485
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
/
+
+
'
'
'
D
D1
D2
H
H1
L
(g)
WDS No.
Steel Screw
WDS No.
Stainless Steel
Screw
M5
40
16.5
31
13
10
16
8485-502CY 8485-602CY
M5
40
16.5
31
13
20
17
8485-504CY 8485-604CY
M5
40
16.5
31
13
40
20
8485-506CY
-
M6
40
16.5
31
13
10
17
8485-508CY 8485-608CY
M6
40
16.5
31
13
20
19
8485-510CY 8485-610CY
M6
40
16.5
31
13
40
23
8485-512CY 8485-612CY
M8
40
16.5
31
13
15
23
8485-514CY 8485-614CY
M8
40
16.5
31
13
30
29
8485-516CY 8485-616CY
M8
40
16.5
31
13
60
41
8485-518CY 8485-618CY
M8
50
18
36
15
15
26
8485-520CY 8485-620CY
M8
50
18
36
15
30
32
8485-522CY 8485-622CY
M8
50
18
36
15
60
44
8485-524CY 8485-624CY
M10
50
18
36
15
20
35
8485-526CY 8485-626CY
M10
50
18
36
15
30
41
8485-528CY 8485-628CY
M10
50
18
36
15
60
60
8485-530CY 8485-630CY
M10
63
22
41
17
20
39
8485-532CY 8485-632CY
M10
63
22
41
17
30
46
8485-534CY 8485-634CY
M10
63
22
41
17
60
64
8485-536CY 8485-636CY
M12
63
22
41
17
30
61
8485-538CY
-
M12
63
22
41
17
60
87
8485-540CY
-
Cadmium Yellow - RAL 1021
ZP
303
RAL
1021
