SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-51
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukKnurled Wheel -
Female Thread
WDS 8485
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
Traffic Red - RAL 3020
D D1 D2 D3
H8
H H1
T
(g)
WDS No. Steel
Threaded Insert
WDS Steel Reamed
H8
Insert
WDS No. Stainless
Steel Insert
M5 40 16.5 -
31 13 10 12.5 8485-202TR
-
8485-402TR
M6 40 16.5 6
31 13 10 12.2 8485-204TR
8485-304TR
8485-404TR
M8 40 16.5 -
31 13 14 11.5 8485-206TR
-
8485-406TR
M8 50 18
8
36 15 14 14.5 8485-208TR
8485-308TR
8485-408TR
M10 50 18
-
36 15 14 14.1 8485-210TR
-
8485-410TR
M10 63 22 10 41 17 14 18.5 8485-212TR
8485-312TR
8485-412TR
M12 63 22
-
41 17 18 17.9 8485-214TR
-
8485-414TR
ZP
303
RAL
3020
Knurled Wheel -
Female Thread
WDS 8485
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
+
+
'
'
'
7
'
7KUHDGHG ,QVHUW
5HDPHG ,QVHUW
Cadmium Yellow - RAL 1021
D D1 D2 D3
H8
H H1
T
(g)
WDS No. Steel
Threaded Insert
WDS Steel Reamed
H8
Insert
WDS No. Stainless
Steel Insert
M5 40 16.5 -
31 13 10 12.5 8485-202CY
-
8485-402CY
M6 40 16.5 6
31 13 10 12.2 8485-204CY 8485-304CY
8485-404CY
M8 40 16.5 -
31 13 14 11.5 8485-206CY
-
8485-406CY
M8 50 18
8
36 15 14 14.5 8485-208CY 8485-308CY
8485-408CY
M10 50 18
-
36 15 14 14.1 8485-210CY
-
8485-410CY
M10 63 22 10 41 17 14 18.5 8485-212CY 8485-312CY
8485-412CY
M12 63 22
-
41 17 18 17.9 8485-214CY
-
8485-414CY
ZP
303
RAL
3020
