SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-99
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukLocating and Clamp Grip
Locating and Clamp
Grip
WDS 8480
WDS 8480
MATERIAL
-
Body - Thermoplastic
Screw - Steel - chemical black
Locking pin - Steel hardened and ground
This product facilitates Locating and
Clamping in one movement with a spring
loaded retractable pin
MATERIAL
-
Body - Thermoplastic
Screw - Steel - chemical black
Locking pin - Steel hardened and
ground
This product facilitates Locating
and Clamping in one movement
with a spring loaded retractable pin
RAL 3020 Traffic Red
RAL 1021 Cadmium Yellow
D
D1
D2
D3
D4
H
H1
H2
L
L1
(g)
WDS No.
5
50 M10 x 1 22.2 28.2 34.8 17.8 11.5
13
5
33 8480-202TR
6
50 M12 x 1.5 22.2 28.2 34.8 17.8 11.5
17
6
40 8480-204TR
8
63 M16 x 1.5 28
35.5
44
22.5 14.5
22
8
97 8480-206TR
10
63 M20 x 1.5 28
35.5
44
22.5 14.5
24
10
135 8480-208TR
D
D1
D2
D3
D4
H
H1
H2
L
L1
(g)
WDS No.
5
50 M10 x 1 22.2 28.2 34.8 17.8 11.5
13
5
33 8480-202CY
6
50 M12 x 1.5 22.2 28.2 34.8 17.8 11.5
17
6
40 8480-204CY
8
63 M16 x 1.5 28
35.5
44
22.5 14.5
22
8
97 8480-206CY
10
63 M20 x 1.5 28
35.5
44
22.5 14.5
24
10
135 8480-208CY
'
'
'
+ +
/
/
'
+
'
'
'
'
+ +
/
/
'
+
'
RAL
3020
RAL
1021
