SECTION 7 - LEVELLING FEET
WDS
WDS
www.wdsltd.co.uk7-1
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSteel Nickel
Plated, Plastic
40mm Base
Levelling Foot
WDS 778
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with
Rubber Pad
Supplied complete with nut
H1
D1
D
L
H
25°
D
L
D1
H
H1
P
(g)
WDS No.
M8
50
40
25
17.5
150
59
778-20140
M8
100
40
25
17.5
150
75
778-20240
M10
50
40
25.5
17.5
250
72
778-20340
M10
100
40
25.5
17.5
250
97
778-20440
M10
150
40
25.5
17.5
250
121
778-20540
M12
100
40
25.5
17.5
300
126
778-20640
M12
150
40
25.5
17.5
300
162
778-20740
M12
200
40
25.5
17.5
300
198
778-20840
M16
100
40
25.5
17.5
400
197
778-20940
M16
150
40
25.5
17.5
400
262
778-21040
M16
200
40
25.5
17.5
400
329
778-21140
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
Steel Nickel
Plated, Plastic
50mm Base
Levelling Foot
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
M8
50
50
29
19.5
700
70
778-20150
M8
100
50
29
19.5
700
86
778-20250
M10
50
50
29.5
19.5
700
83
778-20350
M10
100
50
29.5
19.5
700
108
778-20450
M10
150
50
29.5
19.5
700
132
778-20550
M12
100
50
29.5
19.5
700
137
778-20650
M12
150
50
29.5
19.5
700
173
778-20750
M12
200
50
29.5
19.5
700
209
778-20850
M16
100
50
29.5
19.5
700
208
778-20950
M16
150
50
29.5
19.5
700
273
778-21050
M16
200
50
29.5
19.5
700
340
778-21150
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with
Rubber Pad
Supplied complete with nut
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
H1
D1
D
L
H
25°
