SECTION 7 - LEVELLING FEET
WDS
WDS
www.wdsltd.co.uk7-7
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSteel Nickel
Plated, Plastic
80mm Base
Levelling Foot -
White or Blue
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M8
50
80
25
17.5
150
103
778-20180W 778-20180B
M8
100
80
25
17.5
300
119
778-20280W 778-20280B
M10
50
80
25.5
17.5
400
116
778-20380W 778-20380B
M10
100
80
25.5
17.5
500
141
778-20480W 778-20480B
M10
150
80
25.5
17.5
600
165
778-20580W 778-20580B
M12
100
80
25.5
17.5
300
170
778-20680W 778-20680B
M12
150
80
25.5
17.5
300
206
778-20780W 778-20780B
M12
200
80
25.5
17.5
300
242
778-20880W 778-20880B
M16
100
80
25.5
17.5
400
241
778-20980W 778-20980B
M16
150
80
25.5
17.5
400
306
778-21080W 778-21080B
M16
200
80
25.5
17.5
400
373
778-21180W 778-21180B
Base Pad
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with Rubber
Pad (White Base has Anti-
microbial agent)
Supplied complete with nut
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
Steel Nickel
Plated, Plastic
70mm Base
Levelling Foot -
White or Blue
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M16
100
70
36
26.5
700
286
778-20170W 778-21270B
M16
150
70
36
26.5
700
340
778-20270W 778-21370B
M16
200
70
36.5
26.5
700
416
778-20370W 778-21470B
M20
100
70
36.5
26.5
700
383
778-20470W 778-21570B
M20
150
70
36.5
26.5
700
485
778-20570W 778-21670B
M20
200
70
36.5
26.5
700
586
778-20670W 778-21770B
M24
100
70
36.5
26.5
700
464
778-20770W 778-21870B
M24
200
70
36.5
26.5
700
764
778-20870W 778-21970B
M24
300
70
36.5
26.5
700
1064
778-20970W 778-22070B
Base Pad
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with Rubber
Pad (White Base has Anti-
microbial agent)
Supplied complete with nut
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
H1
D1
D
L
H
25°
H1
D1
D
L
H
25°
