SECTION 7 - LEVELLING FEET
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk7-6
WDS
www.wdsltd.co.ukSteel Nickel
Plated, Plastic
60mm Base
Levelling Foot -
White or Blue
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M8
50
60
25
17.5
150
79
778-20160W 778-20160B
M8
100
60
25
17.5
250
95
778-20260W 778-20260B
M10
50
60
25.5
17.5
300
92
778-20360W 778-20360B
M10
100
60
25.5
17.5
400
117
778-20460W 778-20460B
M10
150
60
25.5
17.5
500
141
778-20560W 778-20560B
M12
100
60
25.5
17.5
600
146
778-20660W 778-20660B
M12
150
60
25.5
17.5
300
182
778-20760W 778-20760B
M12
200
60
25.5
17.5
300
218
778-20860W 778-20860B
M16
100
60
25.5
17.5
400
217
778-20960W 778-20960B
M16
150
60
25.5
17.5
400
282
778-21060W 778-21060B
M16
200
60
25.5
17.5
400
349
778-21160W 778-21160B
Base Pad
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with Rubber
Pad (White Base has Anti-
microbial agent)
Supplied complete with nut
Steel Nickel
Plated, Plastic
50mm Base
Levelling Foot -
White or Blue
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M8
50
50
29
19.5
700
70
778-20150W 778-20150B
M8
100
50
29
19.5
700
86
778-20250W 778-20250B
M10
50
50
29.5
19.5
700
83
778-20350W 778-20350B
M10
100
50
29.5
19.5
700
108
778-20450W 778-20450B
M10
150
50
29.5
19.5
700
132
778-20550W 778-20550B
M12
100
50
29.5
19.5
700
137
778-20650W 778-20650B
M12
150
50
29.5
19.5
700
173
778-20750W 778-20750B
M12
200
50
29.5
19.5
700
209
778-20850W 778-20850B
M16
100
50
29.5
19.5
700
208
778-20950W 778-20950B
M16
150
50
29.5
19.5
700
273
778-21050W 778-21050B
M16
200
50
29.5
19.5
700
340
778-21150W 778-21150B
Base Pad
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with Rubber
Pad (White Base has Anti-
microbial agent)
Supplied complete with nut
H1
D1
D
L
H
25°
H1
D1
D
L
H
25°
