SECTION 7 - LEVELLING FEET
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk7-2
WDS
www.wdsltd.co.ukSteel Nickel
Plated, Plastic
60mm Base
Levelling Foot
WDS 778
H1
D1
D
L
H
25°
D
L
D1
H
H1
P
(g)
WDS No.
M8
50
60
25
17.5
150
79
778-20160
M8
100
60
25
17.5
150
95
778-20260
M10
50
60
25.5
17.5
250
92
778-20360
M10
100
60
25.5
17.5
250
117
778-20460
M10
150
60
25.5
17.5
250
141
778-20560
M12
100
60
25.5
17.5
300
146
778-20660
M12
150
60
25.5
17.5
300
182
778-20760
M12
200
60
25.5
17.5
300
218
778-20860
M16
100
60
25.5
17.5
400
217
778-20960
M16
150
60
25.5
17.5
400
282
778-21060
M16
200
60
25.5
17.5
400
349
778-21160
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with
Rubber Pad
Supplied complete with nut
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
Steel Nickel
Plated, Plastic
70mm Base
Levelling Foot
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
M16
100
70
36
26.5
700
286
778-21270
M16
150
70
36
26.5
700
340
778-21370
M16
200
70
36.5
26.5
700
416
778-21470
M20
100
70
36.5
26.5
700
383
778-21570
M20
150
70
36.5
26.5
700
485
778-21670
M20
200
70
36.5
26.5
700
586
778-20770
M24
100
70
36.5
26.5
700
464
778-21870
M24
200
70
36.5
26.5
700
764
778-21970
M24
300
70
36.5
26.5
700
1064
778-22070
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with
Rubber Pad
Supplied complete with nut
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
H1
D1
D
L
H
25°
