SECTION 7 - LEVELLING FEET
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk7-8
WDS
www.wdsltd.co.ukD
L
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M8
50
25
17.5
150
115
778-20181W 778-20181B
M8
100
25
17.5
150
131
778-20281W 778-20281B
M10
50
26
17.5
250
128
778-20381W 778-20381B
M10
100
26
17.5
250
153
778-20481W 778-20481B
M10
150
26
17.5
250
177
778-20581W 778-20581B
M12
100
26
17.5
300
182
778-20681W 778-20681B
M12
150
26
17.5
300
218
778-20781W 778-20781B
M12
200
26
17.5
300
254
778-20881W 778-20881B
M16
100
26
17.5
400
253
778-20981W 778-20981B
M16
150
26
17.5
400
318
778-21081W 778-21081B
M16
200
26
17.5
400
385
778-21181W 778-21181B
Extended Bolt
Down Base
Levelling Foot -
White or Blue
WDS 778
D
L
H
H1
8.5
25°
9
R15
80
65
Base Pad
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
MATERIAL
-
Stem: Steel - Nickel plated
Base: Polypropylene with Rubber
Pad (White Base has Anti-
microbial agent)
Supplied complete with nut
