SECTION 7 - LEVELLING FEET
WDS
WDS
www.wdsltd.co.uk7-11
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSteel Nickel
Plated with Mild
Steel 80mm Base
Levelling Foot
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
M8
50
80
26.2
24
600
579
778-40180
M8
100
80
26.2
24
600
595
778-40280
M10
50
80
26.7
24
800
592
778-40380
M10
100
80
26.7
24
800
617
778-40480
M10
150
80
26.7
24
800
641
778-40580
M12
100
80
26.7
24
1000
646
778-40680
M12
150
80
26.7
24
1000
682
778-40780
M12
200
80
26.7
24
1000
718
778-40880
M16
100
80
26.7
24
1400
717
778-40980
M16
150
80
26.7
24
1400
782
778-41080
M16
200
80
26.7
24
1400
860
778-41180
M20
100
80
31.8
24
1800
921
778-42480
M20
150
80
31.8
24
1800
1023
778-42580
M20
200
80
31.8
24
1800
1124
778-42680
D
L
D1
H1
H
25°
MATERIAL
-
Stem: Mild Steel - Nickel plated
Pad: Mild Steel
Supplied complete with nut
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
Steel Nickel
Plated with Mild
Steel 100mm
Base Levelling
Foot
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
M16
100
100
34.8
28
1400
1087
778-41200
M16
150
100
34.8
28
1400
1152
778-41300
M16
200
100
34.8
28
1400
1230
778-41400
M20
100
100
34.8
28
1800
1291
778-41500
M20
150
100
34.8
28
1800
1393
778-41600
M20
200
100
34.8
28
1800
1494
778-41700
D
L
D1
H1
H
25°
MATERIAL
-
Stem: Mild Steel - Nickel plated
Pad: Mild Steel
Supplied complete with nut
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
